ABB *ABB SH203-C16 Miniature Circuit Breaker - 3P - C - 16 A

MAKER : ABB Extended Product Type:SH203-C16 Product ID:2CDS213001R0164 Compact Home SH200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 40 A). All MCBs of the product range SH200 comply with IEC/EN 60898-1, allowing the use for residential applications. Standards:IEC/EN 60898-1 Tripping Characteristic:C Rated Voltage (Ur):400 V AC Rated Operational Voltage:acc. to IEC 60898-1 400 V AC Operational Voltage:Maximum (Incl. Tolerance) 440 V AC Minimum 12 V AC Rated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 440 V Rated Impulse Withstand Voltage (Uimp):4 kV at 2000 m 5 kV at Sea Level 6.2 kV Dielectric Test Voltage:50/60 Hz, 1 min: 2 kV Input Voltage Type:AC Rated Current (In):16 A Rated Short-Circuit Capacity (Icn):(AC) 6 kA (400 V AC) 6 kA Rated Conditional Short-Circuit Current (Inc):(230 V) 6 kA (400 V) 6 kA Rated Frequency (f):50 / 60 Hz Power Loss:7.5 W at Rated Operating Conditions per Pole 2.5 W Power Supply Connection:Arbitrary Contact Position Indication:ON / OFF Energy Limiting Class:3 Electrical Endurance:20000 AC cycle Mechanical Endurance (Nendu):20000 cycle Number of Poles:3 Number of Protected Poles:3 Overvoltage Category:III Product Range:SH200 Tightening Torque:2 N·m Actuator Type:Toggle Screw Terminal Type:Cage Terminal Actuator Marking:I / O Actuator Material:Insulation Group II, Black, Sealable Housing Material:Insulation Group II, RAL 7035 Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 Mounting Position:Any Recommended Screw Driver:Pozidriv 2 Accessories Available:No Connecting Capacity:Conductor 25 / 25 mm² Flexible with Ferrule 0.75 ... 16 mm² Flexible 0.75 ... 16 mm² Rigid 0.75 ... 25 mm² Stranded 0.75 ... 25 mm² Installation Size:acc. to DIN 43880 1 Terminal Type:Screw Terminals
