Fluke PJKPL 3760-6 Binding Post, Tin Plt. (blue)

BINDING POST, TIN PLT. (BLUE) The Pomona 3760-6 binding post features bright tin plated brass construction with blue polycarbonate insulation. This model accommodates panels ranging from 0.070 to 0.250 inches (1.77mm to 6.35mm) in thickness. All dimensional tolerances follow standard specifications: .xx dimensions maintain ±.02 inch (±0.51 mm) tolerance, while .xxx dimensions adhere to ±.005 inch (±0.127 mm) tolerance. This binding post supports hands-free operation in controlled voltage environments up to 2500 Vrms maximum. For CE compliance applications, it is not intended for hand-held use at voltages exceeding 33 Vrms/70 Vdc. The component operates within a temperature range up to +239°F (+115°C) and handles maximum current of 15 Amperes.
