HAGER *HAGER 63A 4 POLE 100mA ELCB RCCB - CE463B

MAKER : HAGER MFR PART NO. : CE463B TYPE : Residual Current Circuit Breakers (RCCB) 63A 4P 100MA Number of poles 4 Rated current 63 A Rated fault current 100mA Technical data : nominal voltage : 2 pole 110/230V - 50Hz 4 pole 230/400V - 50Hz specifications : IEC 61008-1 SS97 Connection capacity : 16-63A rigid 25▫ flexible 16▫ 80-100A rigid 50▫ flexible 35▫ Ambient temperature range : -5 to +40°C Positive contact indication : Mechanical indicator, appearing on the front face of the RCCB, linked to the contacts shows the positive opening of all poles, red = contacts closed green = contacts open Earth fault indicator : Mechanical indicator appearing on the front face of the RCCB to differenciate between tripping and off position yellow - tripped Nuisance tripping : All the RCCBs are protected against transient voltages (lightning, line disturbances) and transient currents (from high capacitive circuits). DC sensitive RCCBs or time delay devices are available, please consult us. You also have the possibility to install the following accessories : electrical auxiliaries terminal cover kit locking kit
