Legrand *Legrand P17 Tempra Pro Panel Mount Socket Connectors, IP44

Legrand, P17 Tempra Pro IP44 Red Panel Mount 3P+N+E Industrial Power Socket, Rated At 32A, 415 V Manufacturer: Legrand Mfr. Part No.: 5 552 89 Legrand P17 Tempra Pro panel mount socket connectors, IP44 rating with 2 or 3 pole and earth/neutral arrangement as stated, rated at 16 and 32A. The connector body is constructed from a plastic material, for use with differing voltages as defined by the colour of the cap, yellow 100 to 130V, blue 200 to 250V, red 380 to 415V. Features a single captive screw per terminal for easy connectivity. Standards BS EN 60309-1, BS EN 60309-2, BS EN 60529 (IP), BS EN 62262 (IK) Legrand P17 Tempra Pro Industrial Power Connectors Specifications Attribute Value Current Rating 32A Plug/Socket Socket Pole Format 3P+N+E Voltage Rating 415 V Mounting Type Panel Mount IP Rating IP44 Colour Red Gender Female Body Orientation Straight Termination Method Screw Series P17 Tempra Pro Cable CSA 10.0mm² Maximum Operating Temperature +40°C Minimum Operating Temperature -25
