Moflash *Moflash A2EX Series Metallic Stainless Steel Cable Gland - 50211

Moflash A2EX Series Metallic Stainless Steel Cable Gland, M20 Thread, 11mm Min, 15mm Max, IP66, IP68 Manufacturer: Moflash Mfr. Part No.: 50211 Type : Cable Gland A2EX Compression Gland for Explosive Atmospheres The A2EX Compression Gland is designed for use with unarmoured cable in hazardous areas with a potentially explosive atmosphere. Equipment protection levels: Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex tb IIIC Db II 2G, II 2D, II 3G. For indoor, outdoor and hazardous areas for Group II surface installations Inner seal of seal seals on the cable sheath Outer seal grips the cable, giving superior cable retention and IP rating Precision manufactured from high quality brass (marine grade electroless nickel plated) or stainless steel Complete with a sealing gasket and end cap safety gauge for correct gland selection IP66 / IP68 protection Approvals ATEX, IECEx, INMETRO, SANS/IEC. Specifications Attribute Value Thread Size M20 Maximum Cable Diameter 15mm Minimum Cable Diameter 11mm Material Stainless Steel Colour Metallic Series A2EX IP Rating IP66, IP68 Locknut Included No Hazardous Area Certification ATEX Minimum Operating Temperature -20°C Maximum Operating Temperature +95°C
