PUSR USR-M100 REMOTE IO EDGE GATEWAY RS232 RS485 DI DO AI MQTT MODBUS TCP UDP DIN RAIL MOUNT

Features: - Supports edge computing and real-time data processing - Rich networking protocols: TCP, UDP, HTTP, MQTT, Modbus RTU/TCP -Ethernet-based communication for stable and high-speed data transfer - Interfaces: RS232, RS485, DI (Digital Input), DO (Digital Output), AI (Analog Input) - Remote configuration and firmware upgrades via Ethernet - Industrial-grade design with wide temperature and voltage support - DIN-rail mount for easy industrial deployment Specifications: - Connectivity: 1 × RS232, 1 × RS485, 1 × Ethernet (10/100Mbps), DI × 2, DO × 2, AI × 2 (typical configuration) - Mounting: DIN-Rail - Dimensions: 110 × 80 × 58 mm - Weight: 200 g - Enclosure: Reinforced plastic housing - Power Supply: 9–36V DC wide voltage input - Indicators: LED status lights for power, network, and IO - Wiring: Terminal blocks for IO and serial interfaces - Data Rate Serial: up to 115200 bps - Data Rate Ethernet: 10/100 Mbps auto-negotiation - IO Signal Types: DI, DO, AI - Operating Temperature: -30°C to +75°C - Storage Temperature: -40°C to +85°C
