TP-LINK 5-PORT GIGABIT DESKTOP POE+ SWITCH WITH 1-PORT POE++ IN AND 4-PORT POE+OUT

Feature: - Ports: 5× 10 Mbps/100 Mbps/1 Gbps RJ45 ports - 1-Port Gigabit PoE++ In and 4-Port PoE+ Out: Supports up to 66 W / 47 W / 21 W/ 9 W PoE budget output when powered by 802.3bt Type 4, 802.3bt Type 3, 802.3at, and 802.3af PoE standard, respectively.* - Long-Range PoE+: With Extend Mode**, PoE transmission distance reaches up to 250 m, perfect for surveillance camera deployment in large areas. - PoE Auto Recovery: It guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices. - Metal Casing: Durable metal casing and desktop/wall-mounting design are well-suited for different environments. - Silent Operation: Industry-leading fanless design ensures silent operation, ideal for any home or business. - Plug and Play: No configuration and installation required. - Power Supply: The product only supports PoE power supply, not AC or DC power supply. HARDWARE FEATURES Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1p Interface - 5× 10/100/1000Mbps RJ45 Ports - 1× 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt Type3/bt Type4) - 4× 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at) - AUTO Negotiation - AUTO MDI/MDIX Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100? STP (maximum 100m) Fan Quantity: Fanless Power Supply: Only Powered by PoE Device PoE Ports (RJ45) • PoE In Port: Port 5, Compliance with 802.3af/at/bt Type3/bt Type4 • PoE Out Ports: Ports 1-4, compliance with 802.3af/at • PoE Power Budget: -66 W when powered by 802.3bt Type 4 (90 W) -47 W when powered by 802.3bt Type 3 (60 W) -21 W when powered by 802.3at (30 W) -9 W when powered by 802.3af (15.4 W) Max Power Consumption • 2.68 W (90W PoE In, with no PD connected) • 68.59 W (90W PoE In, with 66 W PD connected) Max Heat Dissipation • 9.112 BTU/h (90W PoE In, with no PD connected) • 233.206 BTU/h (90W PoE In, with 66 W PD connected) PERFORMANCE Switching Capacity: 10 Gbps Packet Forwarding Rate: 7.44 Mpps MAC Address Table : 2k SOFTWARE FEATURES Advanced Features • Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery (Ports 1-4) • Mac Address Auto-Learning and Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping Transfer Method: Store-And-Forward Dimensions ( W x D x H ): 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) Package Contents 1x TL-SG1005P-PD 1x Installation Guide
